Infant Radiant Warmer with Fixed Baby Cradle and Drawers Manufacturer,Supplier and Exporter in India
Product Code : PHICE-11435
Quick answer. Infant Radiant Warmer with Fixed Baby Cradle and Drawers — with Microprocessor based temperature controller with 4 modes Skin / Air / Manual / Prewarm mode. Supplied by Pharmacy Lab Equipment, Ambala.
Description
Collapsible/lockable Side Supports made up of Unbreakable polycarbonate material. Fixed height warmer with attached baby cradle and drawers mounted on 4" (100mm) wheels, 2 with brake. Stainless steel baby tray with water proof, zipped cover mattress of density approx. 21-25 kg/m³. Stainless steel infusion rod with facility to mount Syringe/infusion pump. Lower shelf below baby tray to facilitate under surface phototherapy, Facility of 3 drawers for storage. Microprocessor based temperature controller with Pre-warm, Manual and Skin Servo modes. LED Display of Skin Temp.,Air Temp., Set Temp. (Resolution 0.1°C) & Heater Power %. LCD to display modes of operation, Alarm messages, Skin Temperature in °F and Timer. Thermistor based sensor with Accuracy of +/- 0.2°C (Temp. Calibration not require). Overhead heater box: Swivelling, Consists of Ceramic heater (650 Watts) placed in parabolic reflector with a safety grill & Halogen observation light (12V/50W) for observing the baby. Pre-warm mode: To pre-warm the cradle before baby is placed on the bed. (No alarm will be activated during Prewarm mode) Adjustable Heater Power 0 to 25% (with an increment of 5%), Time duration:30mins.
Key features
- Slots for sensor and ventilator tubing
- Side tray for placement of monitor
- Continuous head up/down facility
- X-Ray cassette holder
- Keypad lock facility
- Power Fail Alarm: Audio with LED indicator
Technical specifications
| Specification | Value |
|---|---|
| Distance between baby bed and heater | 33" (840 mm) |
| Mattress size | 30" (762 mm) x 20" (508 mm) |
| Height of side panel above baby bed | 5.75" (145 mm) |
| Height | 74.5" (1890 mm), Width : 28.0" (710 mm), Length : 39.0" (990 mm) |
| Bed to Floor Height | 37.5" (950 mm) |
| Performance/Electrical Specifications | |
| Skin mode | Temperature range: 34 to 38°C , Resolution : 0.1°C |
| Air mode | Temperature range: Room temp. to 39°C , Resolution : 0.1°C |
| Manual mode | Adjustable Heater Power 0 to 100% (with an increment of 5%), Time duration:15mins |
| Modes of Operation | Skin Servo, Air, Manual and Pre-Warm |
| Operating Voltage | 220-240 VAC, 50Hz, Power: 800W (Max.) |
| Alarm | Audio alarm with 10 minute mute facility & Visual alarms with message on LCD as follows |
| Alarm Condition | Alarm Messages on LCD |
| Skin Sensor is unplugged /Faulty | Skin Sensor Fail |
| Air Sensor is unplugged /Faulty | Air Sensor Fail |
| Measured skin temperature higher than set temperature by 1.0°C | Skin Temp. High |
| Measured skin temperature lower than set temperature by 1.0°C | Skin Temp. Low |
| Measured skin temperature higher than 38.0°C (With cut-off) | Skin Over Range |
| Measured skin temperature lower than 34.0°C | Skin Under Range |
| Measured air temperature higher than set temperature by 1.5°C | Air Temp. High |
| Measured air temperature lower than set temperature by 3.0°C | Air Temp. Low |
| Measured air temperature higher than 39.0°C (With cut-off) | Air Over Range |
| Heater power is 100% for more than 15mins | Chk Sens Position |
| Heater is unplugged or faulty | Heater Open |
| Heater Power drive fail/uncontrollable | Chk. Pwr. Drive |
Confirm the full specification, the standard accessories supplied and the warranty terms against your requirement before ordering.
